LIEBHERR LFS 380 2008
- Zustand: gebraucht
- veröffentlicht: 13/04/2026
- 25IND47590
Technische Daten
- Zustand: gebraucht
- Jahr: 2008
Beschreibung
CNC – Gear Shaping Machine LIEBHERR LFS 380 SIEMENS Sinumerik 840D built 2008
gear Ø 380 mm outside + inside, workpiece Ø 400 / 600 (800) outside/Inside (limited), gear width 200 mm, Center dis ...
CNC – Gear Shaping Machine LIEBHERR LFS 380 SIEMENS Sinumerik 840D built 2008
gear Ø 380 mm outside + inside, workpiece Ø 400 / 600 (800) outside/Inside (limited), gear width 200 mm, Center distance between gear head and table center
min./max. -50/450 mm, Travel range of the lifting position 250 mm, max module 6 mm, max axial travel 250 mm, table Ø 400 mm, centerign hole Ø 200 mm,
table hole Ø 150 mm, numbe of slots 6 piece, milling head 37 kW, max stroke rate 600DH/min, Face milling head axis angle adjustment +/-0,5 °, HSK-B100,
cutting wheel holder mounting 60 mm, milling spindle Ø 110 mm,
